功率 | 巡航速度 | 续航里程 | 有效载荷 |
80 hp | 108 ktas | 831nm | 567lb |
四种飞机的特性
它是滑翔机、快速高效的越野巡洋舰、多功能教练机还是灵活的飞机解决方案?Sinus具有极高的灵活性,可以在几分钟内从滑翔机转变为快速越野飞机。
Sinus将真正的滑翔机与动力飞行过程中前所未有的效率相结合。在短跑道上起飞和降落,越野飞行,享受出色的滑翔能力。全部在同一架飞机上。
燃油效率高,续航里程出色
Pipistrel 的 Sinus 系列飞机是破纪录的飞机,这要归功于其空气动力学效率,同时每小时的燃油量不到 10 升。使用远程油箱,您可以走得更远。
优异的滑行性能
在想象力和创新的推动下,15米长的机翼和高达27:1的滑翔比,当螺旋桨被羽毛化时,让您享受无数小时的热飞行,而不会燃烧一滴燃料。当然,在需要时,您可以随时打开发动机以延长续航里程。
MODEL | SINUS 912 |
ENGINE ROTAX | ROTAX 912 UL2 |
max power(with 2 carb.) | 80 hp at 5800 rpm |
PROPELLER | Pipistrel VARIO |
SIZES | |
wing span | 14,97 m |
length | 6,6 m |
height | 1,70 m |
wing area | 12,26 m2 |
rudder area | 1,1 m2 |
tail area | 2 |
aspect ratio | 18,3 |
positive flaps | 9 deg, 18 deg |
negative flaps | 5 deg |
center of gravity | 20% – 39% |
WEIGHTS | |
empty weight | 285 kg |
empty weight light version | 275 kg |
max take off weight (MTOW) | 450 kg / 472.5 kg / 544 kg |
fuel tanks capacity | 2 x 30 l / 2 x 50 l |
useful fuel | 2 x 27 l / 2 x 45 l |
PERFORMANCES | DATA PUBLISHED FOR MTOM of 472.5 kg |
stall with flaps | 63 km/h |
stall without flaps | 66 km/h |
cruising speed (75% power) | 200 km/h |
max. horizontal speed | 220 km/h |
VNE | 225 km/h |
max speed with airbrakes out | 160 km/h |
max speed with flaps down | 130 km/h |
manoeuvring speed | 141 km/h |
best climb speed | 115 km/h |
max climb rate | 6,5 m/sec |
climb rate at 140 km/h | 6,3 m/sec |
min.sink speed | 90 km/h |
min.sink (prop. 90 deg.) | 1,03 m/sec |
max. sink with airbrakes | 5,5 m/sec |
best glide ratio speed | 95 km/h |
best glide (prop. 90 deg.) | 1:27 |
glide at 150 km/h (prop 90 deg) | 1:18 |
take off run | 88 m |
take off over 15 m obstacle | 148m |
service ceiling | 8800 m |
45°-45° roll time | 4,2 sec |
fuel consumption at cruise speed | 9,2 l/hour |
endurance (std tanks) | 5,8 hours |
range distance | 1200 km |
max load factor permitted ( x1.875) | +4g -2g |
design safety factors & tested | minimum 1.875 |
